This webinar is suitable for any existing or potential PropCad user who is involved in the manufacturing marine propellers. In this webinar, we will debut the Pattern Corrections utility, create a pattern from an existing PropCad design, and demonstrate how adjustments to the pattern can be made rapidly and easily. These manufacturing corrections are applied directly to the propeller’s design parameters, allowing calculation and visualization of the resulting pattern’s sections, blade parameters, and radial distributions.
The new “Pattern Corrections” utility allows users to rapidly create casting patterns, mold geometries, and machining models by specifying the machine stock and shrinkage factors to be applied to the original PropCad design model. Click to watch the recorded webinar (Febru– 11:15AM EST) HydroComp PropCad features a new Premium Edition utility for creating propeller patterns and mold geometries.This webinar is suitable for any existing or potential PropCad user who is interested in reconstructing existing designs in PropCad. Once the design is in PropCad, we will produce additional documentation such as 2D drawings, pitch inspection reports, and 3D offsets can be easily generated for customers, clients, and record keeping. In this webinar, we will demonstrate how Scan Converter processes the data and recreates the propeller blade by extracting individual sections from the geometry and deriving the geometric distributions. The Scan Converter utility – which is now a part of PropCad Premium Edition – is used to extract propeller features such as pitch, chord, skew, rake, thickness and section offsets using 3D data points collected from a physical propeller or pattern. Click to view this recorded webinar (Febru– 11:15AM EST) HydroComp PropCad is often used to interpret existing propellers, patterns, and scan reports in order to recreate legacy designs.The presentation will demonstrate the capabilities of PropCad for new and existing users, and is an excellent way to get a jumpstart on using PropCad 2014 for those who are considering an upgrade. Additionally, we will discuss some advanced features such as Classification Societies, CAD/CAM exports, point cloud scanning, and the new smoothing and design tools. In this presentation, HydroComp will guide you through the new table-based interface, the parametric Builder, and extensively updated Strength & Materials. Join HydroComp for this introduction to propeller design in PropCad 2014.
Hydrocomp propcad 2016 update#
2014 – 10:15AM EST) PropCad 2014 is a powerful update to PropCad 2011 which introduces many new design tools, an updated interface, and powerful new features. Click to view the recorded webinar (October 21.The interactive presentation below is an excellent introduction to PropCad: Our PropCad webinars are available here: At this time, the PropCad demo is unavailable.
